Travel Card Drag

Overview

I built this component to understand how drag interactions can drive engaging UI animations. The goal was to create a stack of cards that feels responsive by combining drag gestures, swipe thresholds, card reordering, and smooth motion transitions.

Learning

The main learning from this component is how to handle the drag interaction by motion.

Let me list down what I learned in each step while building this:

The drag property

To make any Motion element draggable, we just need to pass the drag prop to it. In our case, we want to allow dragging only on the x-axis, so I used this:

drag = "x";

But there is a small hidden issue in our case. Even after making the card container draggable using the drag prop, we still won't be able to drag the cards.

This is because we're rendering an image, and images are draggable by default in the browser. To prevent this behavior, we need to add the pointer-events-none class to the Image component. Only then will the drag interaction work properly.

I also added dragConstraints to limit the drag area for the card. I then added a subtle elastic effect at the edges of the drag area using dragElastic.

Card Behavior

In this component, I added two swipe interactions:

If we drag the top card, it moves to the back of the stack.
If we drag any other card, it moves to the front of the stack.

If you want only the top card to be draggable, you can use:

drag={isTop ? "x" : undefined}

This ensures that only the top card can be dragged.

Swipe Threshold

To avoid accidental swipes, I added a threshold of 80px in both directions. If the card is dragged less than 80px, it snaps back to its original position using dragSnapToOrigin. Only when the drag exceeds this threshold is the swipe action triggered.

onDragEnd={() => {
  if (x.get() > -80 && x.get() < 80) return;
  animate(x, 0);
  handleDragEnd?.();
}}
